Titex Supreme 6597645 DC170 Extra Length Drill, 11.113 mm Drill - Metric, 0.4375 in Drill - Decimal Inch, 311 mm OAL, Solid Carbide
- Manufacturer: Walter
- Brand Name: Titex
- Part Number: TITEX 6597645
- MPN: 6597645
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at Reynolds & Son, Inc - So Barre
- Sold As: 1/PK
-
Price:
Titex Supreme Extra Length Drill, Series: DC170, 11.113 mm Drill - Metric, 0.4375 in Drill - Decimal Inch, 311 mm Overall Length, 20XD Cutting Depth, 2 Flutes, Spiral Flute, 264 mm Flute Length, 12 mm Dia x 45 mm L Shank, Straight Shank, 140 deg Point, Self-Centering Point, Right Hand Cutting Direction, Solid Carbide Cutting Edge, Solid Carbide, Applicable Materials: Non-Alloyed Steel, Low-Alloyed Steel, High-Alloyed Steel, High-Alloyed Tool Steel, Stainless Steel, Malleable Cast Iron, Grey Cast Iron, Cast Iron With Spheroidal Graphite, Hardened Steel and Hardened Cast Iron, Specifications Met: DIN 6535 HA, Yes Through Coolant
| Applicable Materials | : | Non-Alloyed Steel, Low-Alloyed Steel, High-Alloyed Steel, High-Alloyed Tool Steel, Stainless Steel, Malleable Cast Iron, Grey Cast Iron, Cast Iron With Spheroidal Graphite, Hardened Steel and Hardened Cast Iron |
| Cutting Depth | : | 20XD |
| Cutting Direction | : | Right Hand |
| Cutting Edge Material | : | Solid Carbide |
| Drill Size - Decimal Inch | : | 0.4375 in |
| Drill Size - Metric | : | 11.113 mm |
| Flute Length | : | 264 mm |
| Flute Type | : | Spiral |
| Material | : | Solid Carbide |
| Number of Flutes | : | 2 |
| Overall Length | : | 311 mm |
| Point Angle | : | 140 deg |
| Point Type | : | Self-Centering |
| Series | : | DC170 |
| Shank Size | : | 12 mm Dia x 45 mm L |
| Shank Type | : | Straight |
| Specifications Met | : | DIN 6535 HA |
| Through Coolant (Yes/No) | : | Yes |
- Can be used with emulsion and oil
- For interrupted cuts and inclined exits
- Innovative new land design
- 360 deg coolant coverage for maximum cooling
- Continuous guidance for excellent component quality
- Increased productivity thanks to 50% longer tool life with 35% higher cutting values (in comparison with conventional solid carbide drills)
- Reduced manufacturing costs thanks to optimum tool use (the number of grooves indicates the regrind status of the drill)
- Polished flute for optimal chip evacuation
- Maximum carbide mass for maximum process reliability
