Reelcraft® TW86075 OLPT REE-TW86075-OLPT
  1. pin-int

REE-TW86075-OLPT

Reelcraft® TW86075 OLPT Dual Swivel Hose Reel, 9/16-18 Female Hose Outlet, 3/8 in ID x 75 ft L Hose, 200 psi Pressure, 150 deg F

  • Manufacturer: Reelcraft Industries
  • Brand Name: Reelcraft®
  • Part Number: REE-TW86075-OLPT
  • MPN: TW86075 OLPT
  • UPC: 699567000327
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at Reynolds & Son, Inc - So Barre

Reelcraft's exclusive dual swivel design offers and Independent body manufactured from aluminum and hard coated for wear-resistance.

Reelcraft® Hose Reel, Dual Swivel, Series: TW Series, 3/8 in Hose Inside Dia, 75 ft Hose Length, 9/16-18 Female Hose Outlet, 200 psi, 150 deg F, Permanently Lubricated Bearing, Bench/Ceiling/Floor/Truck/Wall Mount, Buna-N Seal, 24 in Length, 6 in Width, 25-3/8 in Height, T Grade, For Use With: Acetylene, Mapp, Propane, Natural and other Fuel Gas

Bearings      :      Permanently Lubricated
Grade      :      T
Height      :      25-3/8 in
Hose Inside Diameter      :      3/8 in
Hose Length      :      75 ft
Hose Outlet      :      9/16-18 Female
Length      :      24 in
Mounting Type      :      Bench/Ceiling/Floor/Truck/Wall
Pressure Rating      :      200 psi
Seal Type      :      Buna-N
Series      :      TW Series
Suitable For Use With      :      Acetylene, Mapp, Propane, Natural and other Fuel Gas
Temperature Rating      :      150 deg F
Type      :      Dual Swivel
Width      :      6 in
  • Leak prevention - the double sealed, special molded O-rings prevent leakage
  • The swivel inlets are both permanently identified with machined grooves on the gas side to assure proper installation
  • Quality finish and corrosion-resistant - individually powder coated components offer the maximum protection from premature corrosion
  • Reinforced steel - the robotically welded steel base offers maximum strength and consistent quality
  • Ideal for locations where space is limited
