REE-5600-OLS

Reelcraft's stainless steel hose reels are ideal for food processing, pre-rinse, wash down, chemical transfer, and industrial-solvent handling. Also suitable for coastal, offshore and on-board ship in marine applications where the harsh salt water spray environment requiring stainless steel reels.

Reelcraft® Hose Reel, Corrosion-Resistant Low and Medium Pressure, Series: 5000, 3/8 in ID x 3/5 in OD x 35 ft L Hose, 300 psi Pressure, 14 in Reel Diameter, 2-1/2 in Reel Width, Retractable Spring Drive, Ceiling/Floor/Truck Bed/Wall Mounting, Stainless Steel Swivel, FKM O-Ring Seal, 14-3/8 in H x 14 in W x 6-1/8 in D Dimensions, Reinforced Stainless Steel, Powder Coated, Silver, Domestic

• Reinforced steel - the robotically welded steel base offers maximum strength and consistent quality
• All steel components are powder coated for maximum corrosion resistance
• Full flow stress free swivel design - the full flow swivel combines the highest grade seal design and materials with bearing areas to insure maximum service life
• The hose is plumbed into the base to eliminate the risk of undue stress on the swivel
• Long life drive spring - declutching arbor virtually eliminates possibility of spring damage due to reverse winding
• Only the highest quality spring steel is used and conditioned to insure there are no imperfections offering maximum service life
• Quiet speed latch - the latch cam is designed for reliable quiet operation
• 3/8 in FNPT reel inlet
• 210 deg F maximum temperature rating
