Morse® 177146 MHS Advanced Hole Saw, 7/8 in Dia, 1-15/16 in D Cutting, M42 HSS-Co 8 Cutting Edge, 1/2-20 Arbor
- Manufacturer: The M.K. Morse Company
- Brand Name: Morse®
- Part Number: MKM 177146
- MPN: 177146
- UPC: 050326177146
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at Reynolds & Son, Inc - So Barre
- Sold As: EACH
-
Price:
The all new advanced bi-metal hole saw by M.K. Morse®. Our latest sawing innovation replaces all current Morse bi-metal hole saw solutions into one, simple optimized powerhouse. Arbor required.
Morse® Hole Saw, Advanced, Series: MHS, 7/8 in Diameter, 1-15/16 in Cutting Depth, 5/6 TPI, 1/2-20 Arbor, 1/4 in Dia x 3-3/32 in L Drill, M42 HSS-Co 8 Cutting Edge, Bi-Metal Body, Toothed Cutting Edge, 195 to 585 rpm Speed, 1/4 in, 3/8 in Chuck, Hex Shank, 1/4 in, 3/8 in Shank, Use Arbor: MA24 and MA34, Red, Applicable Materials: Machinable Metal, Nail Embedded Wood, Plastic, Stainless Steel Alloy and Wood
| Applicable Materials | : | Machinable Metal, Nail Embedded Wood, Plastic, Stainless Steel Alloy and Wood |
| Arbor Size | : | 1/2-20 |
| Body Material | : | Bi-Metal |
| Chuck Size | : | 1/4 in, 3/8 in |
| Color | : | Red |
| Cutting Depth | : | 1-15/16 in |
| Cutting Edge Material | : | M42 HSS-Co 8 |
| Cutting Edge Style | : | Toothed |
| Diameter | : | 7/8 in |
| Drill Size | : | 1/4 in Dia x 3-3/32 in L |
| Series | : | MHS |
| Shank Size | : | 1/4 in, 3/8 in |
| Shank Type | : | Hex |
| Speed | : | 195 to 585 rpm |
| TPI or Pitch | : | 5/6 TPI |
| Type | : | Advanced |
| Use Arbor | : | MA24 and MA34 |
- Bimetal cutting edge for heat and wear resistance
- Patented tooth set assists in slug removal
- Positive tooth rake penetrates quickly and cuts faster
- Solid cap construction reducing vibration, cutting faster
