KEO 103-011200 KEO-103-011250
  1. pin-int

KEO-103-011250

KEO 103-011200 Bell Double End Center Drill, #12 Drill - Wire, 0.0625 in Drill - Decimal Inch, 60 deg, 120 deg Included Angle, 118 deg Point Angle, HSS, Uncoated

  • Manufacturer: ARCH Cutting Tools
  • Brand Name: KEO
  • Part Number: KEO-103-011250
  • MPN: 103-011200
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at Reynolds & Son, Inc - So Barre

KEO Center Drill, Bell Double End, #12 Drill - Wire, 0.0625 in Drill - Decimal Inch, 1/16 in Point Diameter, 3/16 in Diameter Body, 1-7/8 in Overall Length, 2 Flutes, 0.1646 in Flute Length, 3/16 in Dia x 15/16 in L Shank, 118 deg Point, 60 deg, 120 deg Included Angle, Right Hand Cutting Direction, HSS Cutting Edge, HSS, Uncoated

Body Diameter      :      3/16 in
Cutting Direction      :      Right Hand
Cutting Edge Material      :      HSS
Drill Size - Decimal Inch      :      0.0625 in
Drill Size - Wire      :      #12
Finish      :      Uncoated
Flute Length      :      0.1646 in
Included Angle      :      60 deg, 120 deg
Material      :      HSS
Number of Flutes      :      2
Overall Length      :      1-7/8 in
Point Angle      :      118 deg
Point Diameter      :      1/16 in
Shank Size      :      3/16 in Dia x 15/16 in L
Type      :      Bell Double End
