ISCAR 6200317
Iscar 6200317 HELI-GRIP Double End Utility Grooving Insert, Rectangle Shape, GRIP Insert, 3002 Insert, Neutral Cutting, 3 mm W Cutting, Manufacturer's Grade: IC808, TiAlN/AlTiN/TiN, Material Grade: H, K, M, P, S
- Manufacturer: Iscar
- Brand Name: Iscar
- Part Number: ISCAR 6200317
- MPN: 6200317
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at Reynolds & Son, Inc - So Barre
- Sold As: 10/PK
-
Price:
The HELI-GRIP product family is our first choice for general purpose groove turn. Due to the twisted concept, HELI-GRIP inserts are the only double ended inserts in the market that can groove deeper than the inserts length.
Iscar Grooving Insert, Double End Utility, Series: HELI-GRIP, GRIP Insert, 3002 Insert, Rectangle Shape, 3 mm Cutting Width, 1.8 mm Maximum Depth of Cut, Y Chipbreaker, 0.2 mm Corner Radius, 3 mm Width, 16 mm Length, Manufacturer's Grade: IC808, ISO Code: GRIP 3002Y IC808, Neutral Cutting Direction, Carbide, TiAlN/AlTiN/TiN, Material Grade: H, K, M, P, S
| Chipbreaker | : | Y |
| Corner Radius | : | 0.2 mm |
| Cutting Direction | : | Neutral |
| Cutting Width | : | 3 mm |
| Finish | : | TiAlN/AlTiN/TiN |
| ISO Code | : | GRIP 3002Y IC808 |
| Insert Size | : | 3002 |
| Insert Style | : | GRIP |
| Length | : | 16 mm |
| Manufacturer's Grade | : | IC808 |
| Material Grade | : | H, K, M, P, S |
| Material | : | Carbide |
| Maximum Depth of Cut | : | 1.8 mm |
| Series | : | HELI-GRIP |
| Shape | : | Rectangle |
| Type | : | Double End Utility |
| Width | : | 3 mm |
