ISCAR 6002418

In addition to highly efficient parting inserts in single and double-ended conventional configurations, Iscar offers a unique double-ended twisted geometry for unlimited depth of penetration. The DO-GRIP ranges also include the largest choice of parting widths available in today's market, covering all applications. Iscar offers a wide variety of chipformers and the most advanced grades to ensure unbeatable performance and extended tool life.

Iscar Parting Insert, Series: DO-GRIP, DGN Insert, 3102J Insert, 3.1 mm Cutting Width, 0 deg Lead Angle, Neutral Lead Angle Direction, 7 deg Relief Angle, Rectangle Shape, 3.1 mm Width, 20.1 mm Length, JT Chipbreaker, 0.2 mm Corner Radius, Manufacturer's Grade: IC328, ISO Code: DGN 3102J IC328, 90 deg Included Angle, Ambidextrous Hand of Insert, Carbide, Material Grade: M, P, S

• First choice for soft materials, parting of tubes, small diameters and thin walled parts
• General applications on low carbon, alloy and austenitic stainless steel
• Low-to-medium feeds
• JS - sharp corner
• IC328 grade - a thin PVD-coated TiCN layer on a P45-K40 substrate
• Very high toughness
• For milling, parting and grooving of steel, stainless and alloy steels at low-to medium cutting speeds and for unstable machining condition
• JT-type chipbreaker - the JT chipformer design is based on the J-type chipformer, with a t-land reinforced frontal cutting edge length
• JT chipformer provides a solution for the intermediate range between the strong and negative C-type configuration and the positive edged J-type chipformer
• The JT chipformer can be used on a wide range of materials, including soft or hard alloy and stainless steel, high temperature alloys and also cast iron
• The JT chipformer deforms the chips into compact shapes, in the same manner as the J-type, but it can be used at higher feeds due to its reinforced edge
