ISCAR 5604102
Iscar 5604102 MULTI-MASTER Interchangeable Milling Head, ANSI Code: MM HR3.0/125-6.5-2T08 IC908, MM HR Milling Tip Style, Chamfer Mill Milling Tip, Solid Carbide, 3 mm Corner Radius, Manufacturer's Grade: IC908, 2 Flutes, Material Grade: H, K, M, P, S
- Manufacturer: Iscar
- Brand Name: Iscar
- Part Number: ISCAR 5604102
- MPN: 5604102
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at Reynolds & Son, Inc - So Barre
- Sold As: 2/PK
-
Price:
Iscar Milling Head, Interchangeable, Series: MULTI-MASTER, MM HR Milling Tip, Chamfer Mill, 12.7 mm Cutting Dia, 12 mm Maximum Depth of Cut, 2 Flutes, 3 mm Corner Radius, Manufacturer's Grade: IC908, ANSI Code: MM HR3.0/125-6.5-2T08 IC908, Solid Carbide, TiAlN, Material Grade: H, K, M, P, S
| ANSI Code | : | MM HR3.0/125-6.5-2T08 IC908 |
| Corner Radius | : | 3 mm |
| Cutting Diameter | : | 12.7 mm |
| Finish | : | TiAlN |
| Manufacturer's Grade | : | IC908 |
| Material Grade | : | H, K, M, P, S |
| Material | : | Solid Carbide |
| Maximum Depth of Cut | : | 12 mm |
| Milling Tip Style | : | MM HR |
| Milling Tip Type | : | Chamfer Mill |
| Number of Flutes | : | 2 |
| Series | : | MULTI-MASTER |
| Type | : | Interchangeable |
