Harvey Tool, 803916, Miniature Drill, Type I, 1/4 in Diameter, E Letter/Wire, 2-1/2 in Overall Length, 2 Flutes, Helical Flute, 0.75 in Flute Length, 6.35 mm Shank, Cylindrical Shank, 90 deg Point, Drill Point, Right Hand Cutting Direction, Solid Carbide Cutting Edge, Uncoated, Applicable Materials: Aluminum/Cast Iron/Steel/Stainless Steel/Wood/Composites
| Applicable Materials | : | Aluminum/Cast Iron/Steel/Stainless Steel/Wood/Composites |
| Cutting Direction | : | Right Hand |
| Cutting Edge Material | : | Solid Carbide |
| Diameter | : | 1/4 in |
| Finish | : | Uncoated |
| Flute Length | : | 0.75 in |
| Flute Type | : | Helical |
| Letter/Wire Size | : | E |
| Material | : | Solid Carbide |
| Number of Flutes | : | 2 |
| Overall Length | : | 2-1/2 in |
| Point Angle | : | 90 deg |
| Point Type | : | Drill |
| Shank Size | : | 6.35 mm |
| Shank Type | : | Cylindrical |
| Type | : | Type I |
- Thinned Web to Reduce Walking
- Self-Centering Point Geometry
- Web Thickness 0.0180 in
