HARRINGTON L5LB030-20 Heavy Duty Lever Chain Hoist, 3 ton Load, 20 ft H Lifting, 69 lb Rated, 1.5 in Hook Opening

  • Manufacturer: Harrington Hoists
  • Brand Name: HARRINGTON
  • Part Number: HARRINGTON L5LB030-20
  • MPN: L5LB030-20
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at Reynolds & Son, Inc - So Barre

Our LB lever hoist forged an entirely new, industry leading benchmark by being smaller, lighter and stronger than any other lever hoist on the market. This hoist can be used horizontally, vertically, inverted or at any other load angle and its proven strength and durability stand up in an endless array of applications.

HARRINGTON Lever Chain Hoist, Heavy Duty, Series: LB, 3 ton Load, 20 ft Lifting Height, 15.6 in Minimum Between Hooks, 1.5 in Hook Opening, 69 lb Pull to Lift, 16.3 in Lever Length, Steel Chain, 1 Reeving, Weston-Type Load Brake, Rubber Grip Handle

Brake Type      :      Weston-Type Load
Chain Material      :      Steel
Handle Type      :      Rubber Grip
Hook Opening      :      1.5 in
Lever Length      :      16.3 in
Lifting Height      :      20 ft
Load Capacity      :      3 ton
Minimum Between Hooks      :      15.6 in
Pull to Lift Rated Load      :      69 lb
Reeving      :      1
Series      :      LB Series
Type      :      Heavy Duty
  • Body - rugged, high impact, all steel construction weighs less than comparable aluminum models
  • Compact and lightweight design
  • Open design for easy inspection and cleaning without dismantling the unit
  • Hooks - forged, heat treated alloy steel hooks open gradually without fracturing under excessive load
  • Top and bottom hooks have heavy duty hook latch
  • Top and bottom hooks rotate 360 deg
  • Operation - rubber grip handle for non-slip operation
  • Operate in close quarters with short handle and 15-degree recovery stroke
  • Patented spring loaded freewheel mechanism for easy adjustment of the load chain and protection against accidental freewheeling under load
  • Gears - highly durable, split-load double reduction gears
  • Induction heat treated and case-hardened
  • Enclosed to protect from dust and moisture
  • Load chain - nickel plated for corrosion resistance
  • Grade 100 heat treated
  • Brake - Weston style load brake with four braking surfaces, two brake pads and two brake pawls for added safety
  • The totally enclosed brake mechanism protects from dirt and moisture
