DEWT-DW090PK
DeWALT® DW090PK Continuous Drive Manual Builder Level Package, 200 ft, Magnification 20X, +/-1/4 in Accuracy, 360 deg Horizontal
- Manufacturer: Stanley Black & Decker
- Brand Name: DeWALT®
- Part Number: DEWT-DW090PK
- MPN: DW090PK
- UPC: 028877473963
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at Reynolds & Son, Inc - So Barre
- Sold As: PACKAGE
-
Price:
The DW090PK 20x Builders Level Package magnifies 20 times for a 200-feet range. Heavy-duty leveling base is fast and easy to set up and level.
DeWALT® Builder Level Package, Continuous Drive Manual, 200 ft Working Range, Magnification: 20X, +/-1/4 in Accuracy, 360 deg Horizontal, 1 deg Horizontal Graduations, 5 ft Minimum Focus, 22 mm Aperture, 3 Leveling Screws, 5/8-11 Mounting, Aluminum
| Accuracy | : | +/-1/4 in |
| Aperture Size | : | 22 mm |
| Horizontal Graduations | : | 1 deg |
| Horizontal Range | : | 360 deg |
| Magnification | : | 20X |
| Material | : | Aluminum |
| Minimum Focus | : | 5 ft |
| Mounting Thread | : | 5/8-11 |
| Number of Leveling Screws | : | 3 |
| Type | : | Continuous Drive Manual |
| Working Range | : | 200 ft |
- Protected levelling vial for jobsite durability
- 360 deg horizontal circle with vernier scale for precise measuring of horizontal angles
- Heavy duty levelling base is fast and easy to set up and level
- +/-1/4 in per 100 ft accuracy
- Transit capability allows user to determine vertical angles
