DEWT-DCN692B

The 20V MAX* cordless 30o paper collated framing nailer features the power to drive a range of fasteners between 2 in and 3-1/2 in for jobsite versatility. Our upgraded engine design delivers increased power and drive quality compared to previous DeWALT® cordless nailers. Its compact shape, well balanced design, and easy-to-operate features make it a highly productive tool that helps pros get the job done quickly and efficiently.

DeWALT® Cordless Framing Nailer Kit, High Performance, Kit Bare Tool/Kit, Series: XR™, 2 to 3-1/2 in Fastener, Paper Collation, 33 deg Collation, 55 Nails Magazine, Rear Load Loading, 0.113 to 0.131 in Shank, Sequential/Bump Trigger, Non-Marring Tip, 20 V DC, Battery Power Source, Lithium-Ion Battery, 4 Ah Battery, Battery Included: No, Plastic Housing Material, Contoured/Overmold Handle, Yellow, 13-1/4 in Overall Length, 4-45/64 in W x 13 in H Dimensions

• Dual-speed motor optimized to drive a wide range of fasteners for a variety of applications
• Tool-free selector switch for sequential or bump fire modes
• Tool-free depth adjustment for precise nail placement
• Stall release lever to reset driver blade in the event of a jam
• Adjustable rafter hook
• Dry fire lock out prevents tool from firing when nails are low
• 33 deg magazine holds up to 55 paper collated nails
• Capable of driving 3-1/2 in fasteners into dense lumber
• Brushless motor and engine design allow the tool to work as fast as the end user with consistent nail penetration into both soft and hard joints
• Sequential operating mode allows for precision placement and the bump operating mode provides the user with production speed
• 2-speed selector switch optimizes speed for fastener lengths
• Easy access to the nosepiece for the removal of jammed nails
• Trigger lock-off allows trigger to be disabled when tool is not in use
• Top cap is impact-resistant and easy to remove for troubleshooting
