BESSEY TWV16-20-15-2K

Bessey® welding table clamps designed for 16 mm matrix tables are available in a wide range of choices for different needs including variable throat depth versions and accessories to complement the clamps. The TW16 series from Bessey® offers clamping elements with a fixed throat depth of 4 in (100 mm) and a clamping capacity of approx. 8 in (200 mm). For increased flexibility the TWV16 series adds 3 more clamps into the mix that have variable throat depth. The variable throat depth may be set to any distance that falls within the min-max range of the sliding arm. Both series are characterized by a tempered profiled rail and forged sliding arm for strength where you need it, as well as the option to choose between three handle variants. The versions with the high quality 2-component plastic handle and the T-bar handle have a smooth-running trapezoidal threaded spindle and replaceable pressure pads that require no tools to install. The lever handle variant has a positive locking ratchet mechanism for controlled, fast and vibration-proof clamping. Many accessories are available, such as V-blocks, variable risers and assorted adapters that enable the use of toggle clamps on matrix tables with 16 mm holes. There are also 4 different adapters that allow use of the TW16 series clamps on woodworking benches with 3/4 in, 20 mm, 1 in and 30 mm bench dog holes.

Bessey® Welding Table Hold Down Clamp, Variable Throat Depth, Series: TWV16, 2500 N Holding Force, 200 mm Maximum Ram Height, Steel

• Precise, individual clamping
• Tempered profile and sliding arm for sprung and elastic clamping
• Infinitely adjustable throat depth
• High quality 2-component plastic handle and tommy bar with rounded ends each with smooth-running trapezoidal threaded spindle and tool-free pressure plate replacement
• 30 to 150 mm D throat

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Bessey_1000L_Catalog.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Bessey_1000L_Catalog.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Bessey_TWV1620152K_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Bessey_TWV1620152K_Specification_Sheet.pdf
