BESSEY KRE3550

The new K Body® REVOlution (KRE) is designed to clamp at 90 deg to the rail with very large clamping surfaces. The ergonomic two part handle includes a steel socket that allows one to apply clamping force using a hex key. While this helpful feature was designed for ease of clamping, it does allow one to provide more clamping force and is particularly helpful for those with wrist strength issues. The operating jaw has undergone some evolutionary changes as well. Position it where you want and start clamping. The easy set-up allows one to position the operating jaw where you want and, it will stay put during set up. The New Bessey® K Body® REVOlution offers a load limit of 2200 lb, an everyday clamping force of 1700 lb and sizes that range from 12 to 98 in.

Bessey® K Body® REVO™ Parallel Bar Clamp, High Performance, 3-3/4 in Throat Depth, 50 in Clamping, Flat Swivel, 5/8 in Screw, 5/8 in Spindle Diameter, 1-9/64 in Bar, 23/64 in Bar Thickness, Cold Drawn Steel Bar, 2 x 3-3/4 in Clamp Face, 1700 lb Clamping, 1-9/64 x 23/64 in Nominal Rail, Ergonomic Handle, 5.148 in L Handle, Plastic Handle

• Designed to clamp at 90 deg with very large clamping surfaces
• Ergonomic 2-component handle with 6 mm steel socket (for hex key)
• Operating jaw stays where you put it for easy set up
• Three removable pressure caps are included, resistant to glue, paint and solvents
• Two work piece supports prevent the clamped material from contacting the steel rail

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Bessey_1000L_Catalog.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Bessey_1000L_Catalog.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Bessey_KRE3512_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Bessey_KRE3512_Specification_Sheet.pdf
