MMMR-08260

3M™ Fire Barrier Composite Sheet CS-195+ is a lightweight intumescent firestop that combines four components into a single system to help slow the spread of fire, smoke and noxious gases. Sheets combine 30-gauge steel, intumescent material, wire mesh and aluminum foil and are easy to handle and install with common trade tools. They are firestop tested for up to 4 hours of fire protection.

3M™, 7100006140, Composite Sheet, Composite, Series: CS-195+, 52 in Length, 28 in Width, Specifications Met: ASTM E814, CAN/ULC S115, Steel

• RIGID CONSTRUCTION - One side bonded 30 ga galvanized steel, the other is reinforced with a hexagonal shaped steel-wire mesh covered with an aluminum foil scrim
• INTUMESCENT PROTECTION - Intumescent sheet used to firestop large openings and seal penetrations against flame spread, smoke and toxic gases
• Forms effective intermittent fire-break within horizontal and vertical cable tray runs
• Easy to install - cut, form and install using common trade tools for nearly any size
• Thermally conductive - allows unwanted heat build-up to escape, helping reduce derating issues
• Re-enterable for new or retrofit installations

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3M_7100011415_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3M_7100011415_Installation_Manual.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3M_7100011415_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3M_7100011415_Specification_Sheet.pdf
