MMMA-39357

3M� Electrically Conductive Adhesive Transfer Tape 9703 is a low-outgassing Z-axis electrically conductive pressure sensitive adhesive (CPSA) tape that helps enable devices to meet electromagnetic compatibility requirements. It's filled with silver conductive particles for interconnection of electronic substrates and can help enable Z-axis interconnects without shorting adjacent circuitry. Featuring high electrical conductivity, this double-sided tape provides low resistance for small contact areas and high frequencies. It provides robust protection against EMI in a range of market segments with low outgassing requirements, especially aerospace and defense.

3M�, 7000001225, Adhesive Transfer Tape, Electrically Conductive, Series: 9703, 36 yd Length, 12 in Width, 2 mil Thickness, PET Liner, Silver, Acrylic Adhesive, 185 deg F Maximum Operating, -40 deg F Minimum Operating

• Low-outgassing acrylic adhesive
• Anisotropic Z-axis electrical conductivity
• Can be applied as die-cut parts or in roll form
• Thermal curing not required
• Easy to use in assembly operations
• PSA tack properties

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3M_7010333907_User_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3M_7010333907_User_Manual.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3M_7010333907_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3M_7010333907_Specification_Sheet.pdf
